H NR 15 CK

15 outer strands (K) compacted 15 adet compact dış toron
12/15 inner strands compacted 12/15 adet compact iç toron

Steel cross Approx Class 1960
Diam Diam Sec o Mass MBL
mm Inch
mm² kg/m kN
12,7 1/2 86,3 0,75 142
13 91,0 0,79 149
14 9/16 106,0 0,92 173
15 122,0 1,06 200
16 5/8 142,0 1,24 230
17 161,0 1,40 261
18 180,0 1,56 291
19 3/4 201,0 1,75 324
20 22,0 1,94 360
21 246,0 2,14 397
22 7/8 270,0 2,35 435 Constant figures for all diam :
23 296,0 2,58 478 ➢ Tol on diam. : + 1% + 4%
24 321,0 2,75 516 ➢ Filling Factor (f) : 27 x 7 = 0,648
25 348,0 3,03 565 31 x 7 = 0,660

25,4 1 350,0 3,05 566 ➢ Torque factor : 0,007

26 378,0 3,29 611 ➢ Modulus of elas cty E : 112000 N/mm²

27 397,0 3,42 644 (+ ou - 4000)
28 1 1/8 437,0 3,80 709 Her çap için özellikler :
28,6 452,0 3,93 734 ➢ Çap toleransı : + 1% + 4%

➢ Dolgu faktörü (f) : 27 x 7 = 0,648
30 496,0 4,32 806
31 x 7 = 0,660
32 561,0 4,87 910
➢ Dönme faktörü : 0,007
34 1 3/8 628,0 5,46 1049
➢ Elastklik modülü E : 112000 N/mm²

36 717,0 6,24 1164
(+ ou - 4000)
38 1 1/2 797,0 6,93 1295
40 874,0 7,58 1418
41 1 5/8 908,0 7,87 1474
42 962,0 8,52 1561
44 1065,0 9,20 1729
44,5 1 3/4 1078,0 9,31 1749
46 1159,0 10,00 1881
48 1 7/8 1254,0 10,85 2035
50 1378,0 11,85 2236
50,8 2 1425,0 12,31 2313
52 1493,0 12,88 2423

Bu tablo b lg lend rme amaçlıdır.
Ürün le lg l bel rt len tekn k özell kler farklılık göstereb l r, HASÇELİK önceden haber ver lmeks z n değ ş kl k yapma hakkına sah pt r.
Özel konstrüks yon, çap ve MBL ç n HASÇELİK Halat le rt bata geç n z.
The spec ficat ons stated n the product may d ffer, HASCELIK reserves the r ght to make changes w thout pr or not ce.
For spec al construct ons, d ameters and MBL please contact w th HASCELIK Halat.
